Darkflash DY470 ATX Hands-on

Perfect for gamers and content creators on a budget who need strong performance and a spectacle to go with their setups, the DY470 balances elegance with engineering on many fronts.

GDGTME Team  •  December 25, 2024

Darkflash DY470 ATX Hands-on
8.5

Darkflash DY470 ATX

For those seeking luxury looks without sacrificing functionality, the Darkflash DY470 ATX PC Case is a distinctive option. Strong competitor in the mid-range case market, its diamond-inspired design, wide cooling support, superior connectivity, and flexible component compatibility At $85.99, this case provides great value with elements meant to improve both performance and appearance—like the pre-installed ARGB fans, infinity mirror, and back-connect compatibility.

THE GOOD
    THE BAD

      Designed for users who want both an art piece and a cooling powerhouse for their setups, the Darkflash DY470 ATX PC Case pushes the edge in combining aesthetics and utility. This case promises a mid-range price point high-end experience with a clear diamond-inspired three-sided tempered glass design and a range of high-performance capabilities.

      Specifications

      Motherboard SupportITX, M-ATX, ATX
      Case Material0.7mm SPCC
      DimensionsHeight: 497mm
      Width: 298mm
      Depth: 473mm
      I/O2x USB3.0
      1x Type-C
      HD Audio
      Reset
      Power
      Compatibility & ClearanceMax GPU Clearance:
      Horizontal: 410mm
      Vertical: 390mm
      Max CPU Cooler Clearance:175mm
      Radiator SupportTop: 360mmSide: 360mm
      Rear: 120mm
      ColorsBlack/White
      PCIe SlotsStandard

      Aesthetics and Build Quality

      Similar to a “diamond cut,” the DY470’s design offers elegance and flair, turning a simple casing into a stunning piece of art. Three ultra-transparent glass panels together with the wave-patterned cable management backplate improve visibility and enable perfect cable organization.

      The packaging comes with the following items inside:

      • DarkFlash DY470
      • Screws
      • Stand-offs
      • Stand-off thumb screw
      • Internal speaker
      • Microfiber cloth
      • Zip ties
      • Manual
      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      Like facets of a gemstone, the case’s form provides a unique panoramic perspective that improves the look of internal components and RGB lighting by means of a 330° immersive experience. Furthermore, the complete-coverage dust filter with pull-out design guarantees that your construction remains pristine even with regular use.

      The case material—0.7mm SPCC steel—lends stiffness and a premium feel by default. It is very weighted for stability but light enough to reposition as needed. The adjustable GPU support bracket is one of the special features; it helps people with larger graphics cards by reducing the possibility of GPU sag.

      Cooling and Airflow

      The DY470 emphasizes a robust cooling ecosystem, supporting up to ten 120mm fans or two 360mm radiators. The four high-performance ARGB fans provided with Hydro Bearing offer effective heat dissipation with rather low noise levels, therefore augmenting cooling by means of strong airflow.

      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      With compatibility at top, bottom, side, and rear, this fan supports practically every zone in the case and provides users with lots of options for building unique airflow routes. The airflow arrangement is meant to bring in cool air from several directions and guarantee minimum temperature accumulation.

      For liquid cooling enthusiasts, the radiator support is especially notable. Rarely at this price range, you can run your CPU and GPU on separate water cooling loops using slots for up to two 360mm radiators. Larger radiators may typically attain lower temperatures with lower fan speeds, therefore this arrangement not only improves the cooling potential but also helps to provide smoother operation.

      Connectivity and Flexibility

      Modern builds need fast data access, and the DY470 satisfies this with its USB 3.2 Gen 2 Type-C connector on the front I/O, enabling quick 10 Gbps data flows. Two USB 3.0 ports and audio jacks allow a range of peripherals without requiring reaching the rear of the case.

      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      Appreciated by cable-management enthusiasts, the case supports back-connect ATX motherboards, a growing trend that let the front seem clean, cable-free. Because wires may be routed out of sight under the motherboard tray, this compatibility offers a benefit in both visual neatness and airflow.

      Performance-Oriented Features

      Regarding expandability, the DY 470 meets the majority of requirements. It fits ATX, Micro-ATX, and ITX motherboards and has a maximum GPU clearance of 410mm (390mm in vertical position), hence even the biggest graphics cards will fit rather easily. Although suitable for most air coolers, CPU cooler height is just 175mm, therefore it might limit options for the bulkiest models.

      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      Designed to meet users who need simple storage expansion, the layout combines two drive bays—one for SSDs and one for HDDs. Those who need lots of storage could feel constrained, but with NVMe SSDs becoming more and more common, this might not be as much concern.

      User Experience and Assembly

      Darkflash’s careful addition of a cable management panel and tool-free access helps the DY470’s build procedure to be streamlined. Another useful innovation is the cable cover plate of the power supply chamber, which lets one seem neat with little work involved. The special “snap-on” design and infinity mirror effect simplify assembly and allow tool-free part placement by means of infinite reflection effects enhancing the RGB configuration.

      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      Assembly is straightforward, even for less experienced builders, due to the clear layout and tool-free design. The back-connect motherboard’s tidy hiding of connections away from the main compartment improves airflow and aesthetics while simplifying cable management.

      RGB Lighting and Personalization

      The DY 470 features an inbuilt RGB controller synchronizing with compatible motherboard software and adjustable ARGB fans. For gamers trying to enhance their immersion, Darkflash also provides a large collection of 16 preset lighting effects along with 10 music rhythm effects where the lights pulse and alter depending on sound input.

      Darkflash DY470 ATX Hands-on
      Darkflash DY470 ATX Hands-on

      Many users find it handy as the RGB joystick interface on the front panel lets users alternate between modes without using software. The RGB arrangement seems more immersive and complete than many other cases in this price range with the infinity mirror side panel and flowing LED edges. This design decision guarantees the case stays aesthetically interesting from all sides, thereby balancing form and function, especially with reference to the reflecting side panel.

      Verdict

      For those seeking luxury looks without sacrificing functionality, the Darkflash DY470 ATX PC Case is a distinctive option. Strong competitor in the mid-range case market, its diamond-inspired design, wide cooling support, superior connectivity, and flexible component compatibility At $85.99, this case provides great value with elements meant to improve both performance and appearance—like the pre-installed ARGB fans, infinity mirror, and back-connect compatibility.
